SW-325 DC PRO

  • 22 Ft. – Max Gate Length
  • 2000 lbs.  – Max Gate Weight
  • 7 Year Residential Warranty
  • 5 Year Comercial Warranty

UL 325 2018 Compliant

Downloads

Brochure

Manual

Architects & Specifier Files

Warranty card

SW-325 DC PRO

Manual (Model Year 2023 or Before)

SHARE

The SW-325DC was designed to both move heavy commercial/industrial gates and to handle the demands of heavy traffic. It’s underarm was designed to have the gate bracket installed at the bottom of the gate in order to preserve a gate’s beautiful design. Also, its easy slide quick release arm was designed to make any installation quick and easy. Mounting options include Pad or Post Mount which must be specified when ordering. The SW-325DC is capable of moving gates up to 2,000Lbs and up to 22 feet.

DC operators are equipped with a control board that offers an array of features that include a programmable relay and leaf delay, slow start/stop algorithm, and solar power capability. The integrated battery backup offers up to two weeks of uninterrupted operation in the event of a power outage. The brushless DC motors are smooth and quiet but are powerful and durable and require zero maintenance.

For more information contact us or your local distributor.

Specs

SW-325 DC PRO
UL 325 2018 Compliant
Max Gate Weight2,000 lbs.
Max Gate Length22 feet
Warranty7 year residential - 5 year commercial
Motor24 VDC brushless – ½ HP motor
Gate SpeedAdjustable 14-25 seconds per 90° opening
Power Options115/230 VAC single phase and 24 VDC solar panel
Duty CycleContinuous
Battery Back UpIntegrated, with (2) 7Ah 12VDC batteries
Battery Back Up CapacityUp to 250 cycles
Temperature Range-40 to 160°
Gearbox Ratio750:1 with internal clutch
Width X Length X Height19” X 25.5” X 21”
Shipping Weight160 lbs. + 30 lbs. arm
Emergency ReleaseEasy slide quick release arm
Belt SizeN/A
Main Sprocket SizeN/A
Chain SizeN/A
Gearbox SprocketN/A
Limit Shaft SprocketN/A
Breaker Requirement20 amp dedicated
Gearbox PulleyN/A
Motor PulleyN/A

Blowout Drawings

SW-325 DC PRO

Part Numbers

SW-325 DC PRO
LINE ITEMAOM PART NUMBERPart name
1SW-325FMFRAME/CHASSIS
2SPD-325PAD MOUNT
3SPT-325POST MOUNT
GEAR BOX
4GBX-325GEAR BOX
1/2 HP DC MOTOR
5MTR-1500BRUSHLESS DC 1/2 HP MOTOR
6MTR-B365BRUSHLESS DC C-PHASE MOTOR BRACKET
CONTROL BOX
7CBX-325CONTROL BOX
8BLDC-ULPCB45CONTROL BOX DC CIRCUIT BOARD
9COM-1003CONTROL BOX RADIO RECEIVER STRIP
10COM-1004CONTROL BOX RESET PUSH BUTTON
11COM-1005CONTROL BOX ALARM BUZZER
12CBC-325CONTROL BOX METAL COVER
13COM-1006CONTROL BOX BRIDGE RECTIFIER
15COM-1014CONTROL BOX LINE-IN HARNESS
LIMIT SWITCH ASSEMBLY
16COM-1007LIMIT SWITCH
17COM-1012LIMIT SWITCH COLLAR
18LSH-325LIMIT SWITCH WIRE HARNESS
19LSB-325LIMIT SWITCH MOUNT BRACKET
POWER SUPPLY BOX
20PSB-325POWER SUPPLY BOX
21PSC-325POWER SUPPLY BOX COVER
22TFR-480POWER SUPPLY BOX TRANSFORMER
23EMI-PCBPOWER SUPPLY BOX BOARD
24PSH-325POWER SUPPLY WIRE HARNESS
25COM-1001POWER SUPPLY BOX 110 OUTLET
26COM-1000POWER SUPPLY BOX SWITCH
BATTERY BOX
27BTB-325BATTERY BOX
28BTY-12707 AH BATTERY
29BTC-325BATTERY BOX COVER
30BTY-H325BATTERY WIRE HARNESS COMPLETE
MISCELLANEOUS
31LPR-1LOOP RACK
32LPR-H325LOOP RACK WIRE HARNESS
33EPC-325EXTERIOR PLASTIC COVER
SHAFT AND CRANK ARM ASSEMBLY
34DST-325DRIVE SHAFT
35SCA-325CRANK ARM
36SCH-325CRANK ARM HUB WASHER
37SQR-325SWINGER QUICK RELEASE
38SPA-325SWINGER PRIMARY ARM
39SSA-300RRSWINGER SECONDARY ARM
40SGB-300RRSWINGER ARM GATE BRACKET
41SAB-300RRSWINGER ARM GATE BRACKET ATTACHMENT BAR
42SAS-325SWINGER ARM SPACER

Similar Products

Accessories

Manufacturer’s Limited Warranty

The Warrantor warrants All SL-100, SL-150, OH-200, SW300, SW325 and SW350 Gate Operators. ALL-O-MATIC INC warrants its gate openers for a period of five (5) years in commercial installations, and for a period of seven (7) years in residential installation to be free from defects in circuitry, motor, gear box and workmanship. This warranty applies from the date of purchase to the original owner.Warrantor will repair or, at its option, replace any device which it finds to require service. This device must be sent to the warrantor at the consumer’s expense. The warrantor will return the repaired or replaced unit to the customer at the consumer’s expense. Labor charges for dealer service or replacement are the responsibility of the owner. These warranties are in lieu of all other warranties either expressed or implied, and ALL-O-MATIC INC shall not be liable for consequential damage. All implied warranties of merchantability and or fitness for a particular purpose are hereby disclaimed and excluded. This limitation is not valid in jurisdictions which do not allow limitation of incidental or consequential damages or limitation of warranty periods. Caution in order to obtain this policy, please complete the registration card and send it by mail within 30 days of purchasing from ALL-O-MATIC INC. or your INSTALLER. If not registered only a one year warranty on all parts will be provided.
